Robotic Cell: Ultrasonic and Infra Red Assembly, Label Application


Nuspark Automotive Case Study

Robotic Cell: Ultrasonic and Infra Red Assembly, Label Application

"Robotic Cell - Ultrasonic and Infra-Red Assembly Fixture, Robotic Label Application
Automatic Assembly System performs ultrasonic and infra-red welding of the car trim panels. Very compact layout and short cycle time.
Automatic System includes:
•    Rotary indexer with nests for the panels
•    Quick changeover for panels modifications
•    Ultrasonic tooling for staking two bosses
•    Infra-red tooling for staking multiple bosses
•    Poka-yoke for short shot detection
•    Poka-yoke for boss presence and complete welding
•    Robot for panel handling and automatic label application
•    Discharge conveyor
•    High speed operation – short cycle time
•    Compact  layout"
