Robotic Cell - Clip Assembly in IP Extension Panel
Robotic Cell - Clip Assembly in IP Extension Panel
Robotic Cell includes two robots and metal clip vibratory bowl feeder.
1st Robot is installed on top of the mold machine:
• Pick four panels up from the cavity
• Transfer and load/keep first two panels into nests for clip insertion
• Reload/keep next two panels into nests for clip insertion
• Unload assembled panels in discharge conveyor
2nd Robot is installed along with the mold machine:
• Picking clips up with four clips gripper from bowl feeder escapement
• Two clips pick up at the time
• Insertion clips into two panels at the time
Bowl Feeder:
• Bowl for metal clips
• Two linear guides and two escapements for two clips simultaneous pick up"
